| 参数名称 | 参数值 |
|---|---|
| Product Status | Active |
| Technology | Magnetic Coupling |
| Number of Channels | 1 |
| Voltage - Isolation | 3750Vrms |
| Common Mode Transient Immunity (Min) | 100kV/µs |
| Propagation Delay tpLH / tpHL (Max) | 65ns, 65ns |
| Pulse Width Distortion (Max) | 60ns |
| Rise / Fall Time (Typ) | 15ns, 15ns |
| Current - Output High, Low | 4A, 4A |
| Current - Peak Output | - |
| Voltage - Forward (Vf) (Typ) | - |
| Current - DC Forward (If) (Max) | - |
| Voltage - Output Supply | 16V ~ 24V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 10-SSOP (0.315", 8.00mm Width) |
| Supplier Device Package | 10-SSOP-BW |
| Approval Agency | UL |
新闻资讯
ROHM Semiconductor 隔离器 - 栅极驱动器 产品 BM61S41RFV-CE2
作为ROHM Semiconductor优质且资深的代理服务商，深圳凌创辉电子有限公司在为您采购BM61S41RFV-CE2时，能够保证原装进口的品质保障以外，价格也是业界最优的，找我们买BM61S41RFV-CE2绝对的现货正品，需要报价和咨询请您随时联系我们，同时我们为方便您了解BM61S41RFV-CE2产品详情，我们提供了pdf在线观看参数资料，助您轻松采购。
BM61S41RFV-CE2供应商,BM61S41RFV-CE2现货,BM61S41RFV-CE2代理商,BM61S41RFV-CE2pdf参数资料,买BM61S41RFV-CE2,BM61S41RFV-CE2报价,BM61S41RFV-CE2库存
